Oscilloscope Functions:
Horizontal
Sample Rate Range: 250MSa/s(Single-channel), 125MSa/s(Dual-channel)
Waveform Interpolation: (sin x)/x
Record Length: Max. 6K for single-channel; 3K samples per dual-channel
SEC/DIV Range : 5ns/div~500s/div 1, 2, 5 sequence
Vertical
A/D Converter: 8-bit resolution,each channel sampled simultaneously
VOLTS/DIV Range: 10mV/div~10V/divat input BNC
Bandwidth Limit, typical: 20MHz
Low Frequency Response (-3db): ≤10Hz at BNC
Rise Time at BNC, typical: ≤5ns
DC Gain Accuracy: ±3% for Normal or Average acquisition mode, 10V/div to 10mV/div
Note: Bandwidth reduced to 6MHz when using a 1X probe.
Acquisition
Acquisition Modes: Normal
Trigger
Type: Edge
Mode: Auto, Normal, single
Level: ±4 divisions from center of screen
Trigger Level Accuracy: 0.2div X volts/div within ±4 divisions from center of screen
Slope: Rising, Falling, Rising & Falling
Source: CH1/CH2

Input
Coupling: DC, AC or GND
Input Impedance,DC coupled: 25pF±3 pF, 1MΩ±2%
Probe Attenuation: 1X, 10X
Supported Probe Attenuation Factors: 1X, 10X, 100X, 1000X
Maximum Input Voltage: 150VRMS
Measurement
Cursor Voltage difference between cursors: △V; Time difference between cursors: △T
Automatic Measurements: Frequency, Amplitude
DMM
Maximum Resolution: 4000 Counts
DMM Testing Modes: Voltage,Current,Resistance,Capacitance,Diode &On-Off
Maximum Input Voltage AC:600V, DC: 800V
Maximum Input Current AC: 10A, DC:10A
Input Impedance : 10MΩ
Diode: 0V~2.0V
On-Off: <50Ω
Standard Accessories:
1 x Probe
1 x Clip Probe
1 x Type Charging Cable
1x Power Adapter Multimeter
1 x Probe

• Is Discontinued By Manufacturer ‏ : ‎ No
• Package Dimensions ‏ : ‎ 9.88 x 7.6 x 4.17 inches; 2.91 Pounds
• Batteries ‏ : ‎ 1 AA batteries required. (included)
• Date First Available ‏ : ‎ January 11, 2019
• Manufacturer ‏ : ‎ Hantek
• Country of Origin ‏ : ‎ China
